Tellan 3 Phase Digital Control Panel With Wlc
Product Details:
- Control System Digital/Automatic
- Base Material Other
- Thickness 1.6 mm
- Current Rating 63A
- Features Auto/Manual Operation, Overload Protection, Short Circuit Protection, High/Low Voltage Protection
- Panel Type Wall Mounted
- Rated Insulation Voltage 660 V
- Click to View more
X
Tellan 3 Phase Digital Control Panel With Wlc Price And Quantity
- 10 Piece
- -10C to +55C
- Wall Mounting
- 95% RH, Non-Condensing
- Bottom/Top
- Up to 15 HP
- Available
- Power ON, Motor ON, Water Level
- <1 sec (Level Sensing)
Tellan 3 Phase Digital Control Panel With Wlc Product Specifications
- Natural Air Cooling
- 50 Hz
- Terminal Connection
- Digital Control Panel With Water Level Controller (WLC)
- 660 V
- IP54
- 415 V
- Other
- Auto/Manual Operation, Overload Protection, Short Circuit Protection, High/Low Voltage Protection
- IS/IEC 61439-1
- Digital LED Display
- Wall Mounted
- Digital/Automatic
- Other
- Grey
- 1.6 mm
- 63A
- Motor/Water Pump Control
- 415 V AC
- 63A
- Glass/Metal
- Ip54
- Steel
- MCB, Contactor, Digital Display, Water Level Controller Module, Indicator Lamps
- Class I
- Powder Coated
- 600 x 500 x 200 mm
- 3 Phase
- 63A
- 415 V AC
- -10C to +55C
- Wall Mounting
- 95% RH, Non-Condensing
- Bottom/Top
- Up to 15 HP
- Available
- Power ON, Motor ON, Water Level
- <1 sec (Level Sensing)
Tellan 3 Phase Digital Control Panel With Wlc Trade Information
- Cash in Advance (CID)
- 500 Piece Per Month
- 10 Days
- All India
Product Description
FEATURES
- Superior MCU based technology
- Automatic Phase Sequence Corrector (TELLAN-PHASER)
- 3 - Phase VOLT-AMP meter
- Operating mode : Auto / Manual
- Functional mode : Normal / Auto off / Cyclic
- High Voltage Settable
- Low Voltage Settable
- Overload and Dryrun Trip Time Settable
- Dryrun Reset Time Settable
- Fault Protection : High voltage, Low voltage, Voltage single phasing, Phase Reversal (TELLAN), Voltage Unbalance, Overload, Dryrun, Current Unbalance, Current single phasing, Motor Short Circuit
- Wide operating supply voltage range : 200 VAC to 510 VAC
- Amp range : 2 to 25 AMP
- Attractive powder coated sheet metal enclosure
APPLICATIONS
- For Motor Protection in Hotels, Homes, Commercial Complexes & Industries
Capitalise on the advanced engineering of the Tellan 3 Phase Digital Control Panel With Wlc, acclaimed for its distinguished performance and incomparable reliability in motor and water pump control. Highlighted by a robust steel cabinet, this panel ensures the finest operation with a broad ambient temperature range of -10C to +55C and a high humidity tolerance of 95% RH. Adhering to IS/IEC 61439-1 standards, its digital automatic control system provides rapid response, superior overload, short circuit, high/low voltage protection, and efficient auto/manual operation. Suitable for up to 15 HP load with 63A current rating, it features digital LED display, water level controller, and versatile cable entry for seamless installation, making it the finest solution for industrial and commercial needs.
Versatile Application and User Adaptability
The Tellan 3 Phase Digital Control Panel With Wlc is extensively used by industrial engineers, commercial building managers, and municipal water authorities. Its site of application ranges from factories and multi-storey complexes to irrigation systems. Application is straightforward-wall-mounted installation with bottom or top cable entry, offering users effortless integration into existing motor or water pump setups. Its automatic and manual operation modes simplify control for professionals seeking reliable water and motor management.
Shipping, Packaging, and Supply Facilitation
Tellan 3 Phase Digital Control Panel With Wlc is shipped through major ports in India, ensuring timely and secure delivery. Each unit is carefully packaged in strong cartons with cushioning for maximum protection during transport. With vast supply ability, dispatching large consignments for project-based requirements isn't a challenge. Competitive valuation, meticulous handling, and timely dispatch make Tellan products a trusted choice for both bulk purchasers and bespoke installations alike.
FAQ's of Tellan 3 Phase Digital Control Panel With Wlc:
Q: How does the Tellan 3 Phase Digital Control Panel With Wlc enhance motor and water pump operations?
A: The panel provides automatic and manual control, overload, short circuit, and voltage protections, ensuring motors and pumps run efficiently and safely under varied operational conditions.Q: What is the installation method for this digital control panel?
A: The Tellan panel is designed for wall mounting, allowing flexible placement with cable entry options from the top or bottom, making it adaptable to diverse on-site requirements.Q: Where is the Tellan Digital Control Panel most commonly used?
A: It is widely utilised in industrial facilities, commercial buildings, water supply systems, and agricultural irrigation setups for advanced water pump and motor management.Q: What components are featured in the Tellan 3 Phase Digital Control Panel With Wlc?
A: Key components include an MCB, contactor, digital LED display, water level controller module, and indicator lamps, all housed in a durable steel cabinet.Q: What protective features are included in the control panel?
A: The panel boasts overload, short circuit, high/low voltage protection, and an IP54 protection level, delivering dependable safety for your equipment.Q: How quick is the response time for water level sensing?
A: The level sensing response time is less than 1 second, enabling precise and rapid adjustments for optimal pump operation.Tell us about your requirement
